UHT Tubular Sterilizer

1. Cov lus piav qhia dav dav:

Peb UHT tubular sterilizer tuaj yeem ua kom tsis muaj kua txiv hmab txiv ntoo, jam, khoom noj siv mis lossis cov khoom siv zoo sib xws.Cov khoom siv tuaj yeem ua tiav cov haujlwm ntawm cov cua sov kom tsis muaj menyuam thiab cua txias ntawm cov khoom, tab sis kuj tuaj yeem tswj tau thiab sau qee qhov tseem ceeb ntawm kev ua haujlwm, xws li kev ua kom tsis muaj menyuam, uas tsis tsuas yog txo cov kev cuam tshuam ntawm tib neeg cov yam ntxwv ntawm kev ua kom tsis muaj menyuam, tab sis kuj sau cov txheej txheem ntau lawm.

UHT tubular sterilizer tuaj yeem muab faib ua tubular sterilizer thiab raj-hauv-tube sterilizer. Tubular sterilizer feem ntau yog siv rau cov ntaub ntawv uas muaj fluidity zoo, tsawg viscosity ntawm cov khoom xws li kua txiv, mis nyuj thiab lwm yam dej haus; Thaum lub raj-hauv-tube sterilizer nrog plaub-txheej casing qauv, yog siv rau cov jam, pulp, maltodextrin thiab lwm yam ntaub ntawv uas tsis muaj zog, siab viscosity.

2. working principle:

UHT Tubular sterilizer yog tsim los ntawm chav dej, cov khoom siv, cov dej kub, qhov cua txias thiab lwm yam. Tag nrho cov khoom no yog compact, nrog me me nyob hauv pem teb thiab yooj yim rau thauj thiab nruab.

Cov ntaub ntawv tuaj yeem ua tiav tom qab ob peb txheej txheem ntawm preheating, cua sov kom tsis muaj menyuam, cua txias thiab lwm yam.Cov ntaub ntawv pauv cov cua sov nrog cov cua sov tawm los ntawm cov raj nyias nyias. Cov ntaub ntawv ntws hauv cov raj xa dej ntawm ib tus nqi, thiab cov khoom siv hluav taws xob tau ntws hauv cov kav dej sab nrauv, kom sov lossis txias cov ntaub ntawv.Yog tias qhov kub thiab txias, tus nqi ntws, siab thiab lwm yam hloov pauv, lawv yuav cuam tshuam rau kev ua kom tsis muaj menyuam. Tsis tas li ntawd, chav dej, dej txias lossis cov dej ntws los ntawm cov khoom siv sab nraud, yuav tsum ua kom ruaj khov siab, tus nqi ntws, qhov kub thiab txias (raws li cov dej khov dej khov) vim tias cov kev hloov no yuav cuam tshuam rau cov khoom siv kom tsis muaj menyuam.

3. Technical Parameters:

4. Cov yam ntxwv ntawm cov khoom siv:

1. Qhov sib txawv me me ntawm cov cua sov nruab nrab thiab cov khoom siv kom muaj cua sov nruab nrab. Lub casing tube qauv nrog daim iav polishing tuaj yeem txo qhov scaling tsawg dua thiab ua rau cov sij hawm ua hauj lwm ntawm cov sterilizer.

2. High degree ntawm automation.Automatic tswj thiab sau tag nrho cov txheej txheem los ntawm cov cuab yeej CIP, SIP rau tag nrho cov khoom sterilization txheej txheem.

3. Kev tswj kub kom tsis muaj menyuam yog qhov tseeb thiab txhim khu kev qha: cov yam ntxwv uas cuam tshuam rau qhov ntsuas kub kom tsis muaj menyuam, xws li chav siab, ntws, cov khoom ntws thiab lwm yam yog tswj hwm nruj heev.

4. Lub kaw lus muaj kev ruaj ntseg thiab kev ntseeg siab.Tag nrho cov khoom tseem ceeb xws li cov khoom siv twj tso kua mis, lub twj tso kua dej kub, txhua yam li qub thiab cov khoom siv hluav taws xob yog lub ntiaj teb sab saum toj hom. Thiab cov qauv tsim muaj kev tiv thaiv siab thiab lub tswb nrov.

5, Nruab nrog SIP system.

5. Duab:

6. Kev teeb tsa:

Tag nrho cov khoom ntawm peb cov sterilizer yog ua los ntawm lub ntiaj teb no-nrov hom nrog zoo heev thiab txhim khu kev qha kev ua tau zoo, xws li Schneider relays, Airtac cylinders, thiab Spirax Sarco chav valve pawg, kom ruaj khov thiab nruam sij hawm ntau lawm.

Hom ntawm qhov tseem ceeb 1
Tsis muaj.	1	2	3	4	5
Yam khoom	Cov khoom sib npaug tank thiab qib tswj	Centrifugal twj rau SIP thiab CIP	Khoom ntsia hlau twj tso kua mis los yog centrifugal twj tso kua mis	Human Machine Interface (HMI) thiab PLC	SUS304 ywj siab tswj hluav taws xob txee
Hom

Hom ntawm qhov tseem ceeb 2
Tsis muaj.	1	2	3	4	5
Yam khoom	SUS304/316 Tubular tshav kub exchanger Pipes	Cov kav dej, li qub, lub luj tshib, cov kab teeb liab sab hauv, engineering thiab programming	Zaus converters	Chav tswj valve systems	Multi-function Tank
Hom
